What is the working principle of seaweed egg rolls equipment?

The working principle of seaweed egg rolls equipment mainly includes the following key parts: pre forming unit, conveying unit, forming unit and slitting unit.

Pre formed unit: This unit includes a frame, rice supply components, seaweed sheet supply components, and pre formed components. The rice supply component is responsible for quantitatively supplying rice slurry or similar raw materials to the pre formed component, while the seaweed supply component ensures that the seaweed slices are accurately placed under the pre formed component. Pre formed components are initially formed into strip-shaped shapes through specific molds and temperature control, preparing for the subsequent wrapping process.

Conveyor unit: As a key component connecting the preform unit and the forming unit, the design of the conveyor belt needs to consider smooth conveying and precise alignment. The conveyor belt is installed on the frame, not only carrying the pre formed rice strips, but also accurately conveying the rice strips to the forming unit through precise transmission control.

Forming unit: This is the core part of the seaweed roll forming machine, including the first stage single-sided wrapping component, the second stage reverse wrapping component, and the third stage forming component. During the transportation process, the rice strips are first wrapped on one side with seaweed sheets by the first stage single-sided wrapping component, and then enter the second stage reverse wrapping component to achieve comprehensive coverage of seaweed sheets. Finally, in the three-level molding component, the final seaweed roll shape is formed through further compaction and shaping.

Cutting unit: set after the forming unit, its main function is to cut the continuously produced seaweed rolls according to the set length to form independent finished products. The slitting unit is equipped with two independent slitting conveyor belts and high-precision slitting knives to ensure cutting accuracy and efficiency.

Through the cooperation of these parts, the seaweed eggn rolls equipment can efficiently and stably produce seaweed egg rolls products.
